Product Details
＋
Product Features
- AC circuit breaker
- Hydraulic-magnetic technology
- Available in ratings of 70A to 125A
- Precision tripping characteristics
- Trip indication with mid-trip position
- Rest immediately after overload
Application
- AC branch circuit protection
- Telecom / datacom equipment
- Lighting control
- UPS equipment
- Alternative energy equipment
- Mobile power generation equipment
- Railway signalling equipment
- Residential equipment
- Industrial equipment
Safety Features
- Miniture Circuit Breakers should be installed by a trained professional to prevent any damages or injury caused by incorrect installation
Technical Specifications
| Colour: | Black |
| Material: | Plastic |
| Handle Colour: | White |
| Mounting Type: | Dual Mount |
| Number of Modules: | 1 |
| Poles: | 1 |
| Curve: | 2 |
| Protection Type: | Overload and short circuit protection |
| Escutcheon: | 57mm |
| Current: | Available in ratings of 70A to 125A |
| kA Rating: | 6kA |
| Height: | 113.4mm |
| Width: | 26mm |
| Weight: | 200g |
Technical Documents
| Technical Document: |
